1. Assemble the Rotating Rectangular Cover to the Cone of the Main body.
For assembling the Rotating Rectangular Cover to the
Cone, turn the Rotating Rectangular Cover 45 degrees
and check the Click sound to make sure the assembly is
complete.
2. Turn the Outer Ring of the Rotating Rectangular Cover to adjust the angle roughly.
3. Turn the Inner Ring of the Rotating Rectangular Cover to fine-tune the angle.
The disassembly method of the Rotating Rectangular
Cover is the same as the assembly method. Refer to the
NOTE mentioned below stage 1.
