Appendix
EzRay Air Wall (VEX-S300W) User Manual 59
ENGLISH
A.2 Tables of Exposure Times (Default)
The following exposure timetables were established with a unit equipped with a cone
that corresponds to a focus-to-skin distance of 200 mm (8 inches), respectively.
 65 kV, 3.0 mA
Receptor Patient Teeth
Angle of
inclination
SSD: 200 mm (8 inches)
kV mA s
Sensor
Adult
Incisor
Maxilla: +45˚
Mandible: -25˚
65 3.0 0.14
Canine
Maxilla: +45˚
Mandible: -20˚
65
3.0 0.16
Molar/
Premolar
Maxilla: +30˚
Mandible: -5˚
65
3.0 0.18
Bitewing
+5˚~ +8˚
65 3.0 0.19
Child
Incisor
Maxilla: +45˚
Mandible: -25˚
65 3.0 0.11
Canine
Maxilla: +45˚
Mandible: -20˚
65 3.0 0.13
Molar/
Premolar
Maxilla: +30˚
Mandible: -5˚
65
3.0 0.15
Bitewing
+5˚~ +8˚
65 3.0 0.16
