15. Appendices
154 Green Smart User Manual
15.1.3 CBCT Mode
Exposure Area
FOV (cm) Vertical Position
Horizontal Position
Right Center Left
10x8.5 Occlusion X O X
10x7 Occlusion X O X
5x5
Maxilla /
Mandible
Right Molar / Right / Incisor / Left / Left Molar
 10x8.5 (cm) and FOV 10x7 (cm) capture full arch area. (10x8.5 (cm) : Adult mode,
FOV 10x7 (cm) :Child mode)]
Exposure Condition (Scan Time: 18.0 s)
FOV (cm) Image Option
Gender /
Age
Group
X-ray
Intensity
Tube
Voltage
(kVp)
Tube
Current
(mA)
10x8.5
/ 10x7
/ 5x5
High
Resolution
Man
Hard 95 8.7
Normal 94 8.7
Soft 93 8.7
Woman
Hard 95 8.4
Normal 94 8.4
Soft 93 8.4
Child
Hard 95 8.1
Normal 94 8.1
Soft 93 8.1
Green
Man
Hard
80 5.0
Normal
79 5.0
Soft
78 5.0
Woman
Hard 80 4.7
Normal 79 4.7
Soft 78 4.7
Child
Hard 80 4.4
Normal 79 4.4
Soft 78 4.4
