4. Imaging System Overview
Green Smart User Manual 27
ENGLISH
PANO Main Screen
No. Function Description
1
Examination mode
selection panel
Displays available PANO Examination programs.
(In PANO – Orthogonal mode, press UP/DOWN button
to scroll through next/previous ROI option.)
2 CONFIRM button Confirms the settings and moves to the next step.
3 BACK button
Moves back to the modality (PANO / CEPH (Optional) /
CBCT / MODEL) selection screen.
4 Settings button
Adjusts Tube voltage, Tube current, Gender / Age
group, X-ray Intensity, Examination type, Imaging type,
Arch selection, and Image option.
5
Imaging parameter
settings information
Displays the current setting information. (Modality, Tube
voltage, Tube current, Arch type, Image option, and
Pano option.)
