4. Imaging System Overview
28 Green Smart User Manual
PANO Settings Screen
No. Function Description
1
kVp / mA
control button
Adjusts Tube voltage (kVp) and Tube current (mA).
2
Patient’s
Gender / Age
group
Selects patient's Gender / Age group.
3 X-ray intensity
Selects X-ray intensity.
Depending on the circumference of the patient’s
head, X-ray intensity may be classified as Hard,
Normal, or Soft :
Soft ≤ Normal ≤ Hard
4
Examination
Program
Selects between Normal and Special.
5 Pano Option
Selects between Normal, Insight PAN and Magic PAN
(Optional).
6 Arch Selects available patient's Arch types.
7 Image Option
The default is “High Resolution.” “Green” is optional.
- When “Green” is enabled, Image Option is selectable
between “High Resolution” and “Green.” When “Green” is
disabled, Image Options section is invisible.
(Image quality: High Resolution > Green)
