4. Imaging System Overview
30 Green Smart User Manual
CEPH Main Screen
No. Function Description
1
Examination
selection panel
Displays available CEPH Examination programs.
2 CONFIRM button Confirms the settings and moves to the next step
3 BACK button
Moves back to the modality (PANO / CEPH (Optional) /
CBCT / MODEL) selection screen.
4 Settings button
Adjusts Tube voltage, Tube current, Gender / Age
Group, X-ray Intensity, and Image Option.
5
Imaging parameter
settings information
Displays the current setting information. (Modality, Tube
voltage, Tube current, and Image option)
