4. Imaging System Overview
32 Green Smart User Manual
CBCT Main Screen
No. Function Description
1 FOV selection panel Displays available FOV modes.
2 CONFIRM button Confirms the settings and moves to the next step.
3 BACK button
Moves back to the modality (PANO / CEPH (Optional) /
CBCT / MODEL) selection screen.
4 Settings button
Adjusts Tube voltage, Tube current, Gender / Age group,
X-ray intensity, Image Option, and Voxel Size.
5
Imaging parameter
settings information
Displays the current setting information. (Modality, Tube
voltage, Tube current, Image option, and Voxel size)
