7. Acquiring PANO Images
72 Green Smart User Manual
7. Guide the patient to press the base of the nose (acanthion point) against the Chinrest and
tilt the head forward about 5˚. At this point, make sure the patient's jaw does not touch the
equipment.
If the jaw touches the equipment, it is difficult to maintain the proper
position to get good images.
Be careful the patient does not touch the equipment with his/her
jaw.
8. Let the patient maintain the posture as follows:
Open the mouth.
Place the tongue on the roof of the mouth.
Close the eyes.
As shown in the picture, the support unit of the integrated Chinrest
should touch the patient's acanthion point.
Ask the patient to maintain his/her position until the operation is
completed.
