8. Acquiring CEPH Images (Optional)
90 Green Smart User Manual
8.3.1 Lateral / Full Lateral (Optional) Mode
Correct posture reduces the shadow cast by the patient's cervical spine
and allows clear image acquisition.
Patient Positioning
1. Turn the Nasal Positioner to the Lateral mode Positioning Marker as shown below.
2. Leave enough space between the Ear Rods.
Use the Porion Position Reference Indicator that appears in the acquired
image to easily confirm the location of Porion.
3. Guide the patient to the CEPH unit.
4. Direct the patient to relax his/her neck and shoulders and stand upright.
5. Use the Column UP/DOWN button or switch option to adjust the height of the CEPH unit
to approximately match the height of the patient.
After adjusting the height of the column, align the Ear Rods and Nasal
Positioner to the patient.
To Next Page
