User manual
17
⑤ Select Pateint Button
Select the patient per gender (Man, Woman, Child) and bone density (Hard, Normal, Soft).
⑥ Cephalo Property Button
Select Cephalo Mode.
(Fixed to one mode of Quick and Normal Cephalometric depending on specification of
equipment).
⑦ Select Cephalo Imaging Mode Button
Lateral, Frontal, SMV, Carpus are available.
⑧ Lamp Button
Turn the lamp On/Off for arrangement of pateints.
⑨ Select Imaging Mode Button
Select one of imaging mode such as Panorama or Cephalo.
⑩ Confirm Button
Confirm the current setting.
⑪ Ready Button
Perform imaging according to instruction message after clicking Ready Button.
⑫ Imaging, Image Processing Status Bar (Progress bar)
Show the progress status with a graph at the time of imaging and image processing.
⑬ Exit Button
Exit the imaging program.
This software architecture may differ depending on specification of your product
and can be subject to change without notice for improvement of product
performance.
