Installation manual
15
[Components in Packages]
No. Part Name Specification Q'TY
1
Vertical Column
Assembly,
Rotating Unit Assembly
With Vertical Handler 1
Vertical Front Case+LED Case 1
Vertical Top Case 1
Vertical Left Case 1
Vertical Right Case 1
Column Back Case Cover 1
Base Foot Board 1
3.2. Checking Carton No. 1
[Components in carton No. 1]
If the serial numbers don’t match, please don’t install the system.
Please make sure each carton isn’t damaged.
No.
Picasso Duo
Description Q’TY
1 Column and Rotating unit assembly 1
2 Rotator upper cover 1
