Installation manual
33
4.2. Balancing the system after finishing unit assembly
<Balance the system on the ground>
Prepare the spirit level
Position the Rotating unit parallel to the column, as shown below
Please balance the Left and Right of the unit
To do this, put the Level on the Column Carriage and adjust the balance, while observing it, by
turning the bolts on both sides of the base plate [No. ]
1
1
