Installation manual

4.1. Assembling the column and the base plate

Step 1. Attach the column on the base

1-1. Unpack the Picasso Duo and assemble the column with the base plate, as shown below.

1-2. Insert the Base bracket (Accessory No.34) through the bottom of the column.

Please keep a minimum of 300mm distance from the wall because you need space

for cable work & covers assembly on the backside.

[Base support Block]

Down
