4
PaX-Duo3D
Guidelines for Protection against Radiation
The X-ray system may cause injury to the patient if used improperly. The instructions contained in this
manual must be read and followed when operating PaX-Duo3D. The world standard regulations
pertaining to radiation safety must be observed.
When exposing X-ray, User must be behind a protective wall, or take other protective actions. User
should keep at least 2m (7feet) away from the X-ray system when pressing the exposure switch while
observing the patient and capture-progress.
User must provide protective clothing to the patient. Before capturing, a pregnant woman must always
consult with the doctor.
X-ray Room for System Installation
Recommended Minimum Space
● PaX-Duo3D (L)1490*(W)1057*(H)2346 mm
- Above space is established considering the movements of both system operator and patient.
- The system is normally installed beside a wall, and operator uses the system on the left.
Width of Door
- The door of the X-ray room should have a clearance of more than 800mm wide to provide enough
space for transporting the system inside.
Floor area
- The floor of the X-ray room should be stable for system balance.
- The floor should also be able to support a minimum weight of 500KG.
Power Supply
- For system stability, please guarantee 3KW power supply.
Protection against radiation
- For protection against radiation, follow the government or local standards.
Safety Zone
- Check the safety zone.
Do not use this system in a place where there is danger for explosion.
