PaX-Primo
16
1.12.2. High volt
age generator
z
T
ube voltage:
50 to 80kV constant potenti
a
l
z
T
ube current:
2 to 10 mA
direct current
1.12.3. X-Ray gene
ration controller
z
Focal spot length to Sensor:
678 mm
z
Exposure
time:
20sec.
z
Cooling:
1
min.
cooling
time
z
X-Ray generation limit:
50 to 90 kV and 2 to 10 mA
1.12.4. Beam limiter
z
Whole size:
35mm x38 mm x4mm
z
Hole size:
0.87 mm x 18.48 mm x 2.5
mm
z
Material
used:
Lead
(Pb)
17
19
Table of Contents
