Installation manual
17
1.13. System Characteristics
1.13.1. Mechanical Characteristics
z Source to Image distance [Focal spot to Sensor] 603.8mm
z Vertical column movement Max. 700 mm
z Weight 78 kg
z Length x Width x Height 1150mmx950 x2200 mm
z Type of installation Base Stand
1.13.2. Electrical Characteristics
z Power supply voltage AC 110/230V ± 10%
z Frequency 50/60 Hz
z Power rating 2.0KVA
1.13.3. Environmental Characteristics
z Operating temperature 10 ~ 30℃
z Operating relative humidity 30 ~ 75%
z Operating atmospheric pressure 700 ~ 1060 hPa
z Transport and storage temperature -20 ~ 70℃
z Transport and storage relative humidity < 90% non-condensing
z Transport and storage atmospheric pressure 500 ~ 1060 hPa
