Operating & Mounting instructions – 8 074 143.03/03 – Appendix A2
No. Parameter name Factory default Setting Page
A006 O2 Control selection 00 21
A011 External frequency start O (0...10V) 0,00 Hz 19
A012 External frequency end O (0...10V) 0,00 Hz 19
A013 Analog signal ref. for Start O (0...10V) 0 % 19
A014 Analog signal reference for end O (0...10V) 100 % 20
A015 External frequency start pattern O (0...10V) 01 20
A016 Time constant for analog signals 30 21
A019 Multi speed selection 00 22
A020 Internal pre-set speed if A001=02 0,00 Hz 18
A220 2nd Internal pre-set speed 0,00 Hz 54
A021 Multi speed 1 0,00 Hz 22
A022 Multi speed 2 0,00 Hz 22
A023 Multi speed 3 0,00 Hz 22
A024 Multi speed 4 0,00 Hz 22
A025 Multi speed 5 0,00 Hz 22
A026 Multi speed 6 0,00 Hz 22
A027 Multi speed 7 0,00 Hz 22
A028 Multi speed 8 0,00 Hz 22
A029 Multi speed 9 0,00 Hz 22
A030 Multi speed 10 0,00 Hz 22
A031 Multi speed 11 0,00 Hz 22
A032 Multi speed 12 0,00 Hz 22
A033 Multi speed 13 0,00 Hz 22
A034 Multi speed 14 0,00 Hz 22
A035 Multi speed 15 0,00 Hz 22
A038 Jogging frequency 1,00 Hz 23
A039 Stop mode of jog function 00 23
A041 Torque boost method selection 00 24
A241 2nd Torque boost method selection 00 54
A042 Manual torque boost setting 1,0 % 24
A242 2nd Manual torque boost setting 1,0 % 54
A043 Manual torque boost frequency point 5,0 % 24
A243 2nd Manual torque boost frequency point 5,0 % 54
A044 V/f characteristic setting 00 24
A244 2nd V/f characteristic setting 00 54
A045
Voltage gain setting 100 % 25
A051
Selection of DC braking 00 26
A052
DC braking: frequency 0,50 Hz 26
A053
DC braking: waiting time 0,0 s 26
