Operating & Mounting instructions – 8 074 143.03/03 – Appendix A3
No. Parameter name Factory default Setting Page
A054
DC braking: braking torque 0 % 26
A055
DC braking: braking time 0,0 s 26
A056
DC braking: edge/level selection 01 26
A057
DC braking: braking torque (start) 0 % 26
A058
DC braking: braking time (start) 0,0 s 26
A059
DC braking: carrier frequency 3,0 kHz 26
A061
Frequency upper limit 0,00 Hz 29
A261
2nd Frequency upper limit 0,00 Hz 54
A062
Frequency lower limit 0,00 Hz 29
A262
2nd Frequency lower limit 0,00 Hz 54
A063
1st Jump frequency 0,00 Hz 30
A064
1st Jump frequency width 0,50 Hz 30
A065
2nd Jump frequency 0,00 Hz 30
A066
2nd Jump frequency width 0,50 Hz 30
A067
3rd Jump frequency 0,00 Hz 30
A068
3rd Jump frequency width 0,50 Hz 30
A069
Acceleration stop frequency 0,00 Hz 35
A070
Acceleration stop time 0,0 s 35
A071
Selection of PID function: ON/OFF 00 32
A072
PID controller: Proportional gain (kp) 1,0 32
A073
PID controller: Integral gain(Tn) 1,0 32
A074
PID controller: Differential gain(Tv) 0,00 32
A075
PID controller: Scale conversion 1,00 33
A076
PID controller: Feedback destination 00 33
A081
Selection of AVR function 02 34
A082
Selection of voltage for AVR 400 V 34
A085
Operation mode selection 00 57
A086
Energy saving response 50,0 57
A092
2nd Acceleration ramp 15,00 s 34
A292
2nd Second acceleration ramp 15,00 s 55
A093
2nd deceleration ramp 15,00 s 34
A293
2nd Second deceleration ramp 15,00 s 55
A094
Select method of 2nd stage 00 34
A294
2nd Method of second stage selection 00 55
A095
Switch-over 1./2. acceleration ramp 0,00 Hz 35
A295
2nd Stage Acceleration change over point 0,00 Hz 55
A096
Switch-over 1./2. deceleration ramp 0,00 Hz 35
A296
2nd Stage Deceleration change over point 0,00 Hz 55
A097
Pattern of acceleration ramp 00 35
A098
Pattern of deceleration ramp 00 35
