Operating & Mounting instructions – 8 074 143.03/03 – Appendix A4
No. Parameter name Factory default Setting Page
A101 External frequency start OI (4...20mA) 0,00 Hz 19
A102 External frequency end OI (4...20mA) 0,00 Hz 19
A103 Analog signal ref. for Start OI (4...20mA) 0 % 19
A104 Analog signal ref. for end OI (4...20mA) 100 % 20
A105 Ext. frequency start pattern OI (4...20mA) 01 20
A111 External frequency start O2 (-10...+10V) 0,00 Hz 19
A112 External frequency end O2 (-10...+10V) 0,00 Hz 19
A113 Analog signal ref. for Start O2 (-10...+10V) -100 % 19
A114 Analog signal ref. for end O2 (-10...+10V) 100 % 20
A131
Acceleration curve constant 02 35
A132
Deceleration curve constant 02 35
b-Parameters
No. Parameter name Factory default Setting Page
b001
Selection of restart mode 00 50
b002
Allowable undervoltage time 1,0 sec 50
b003
Retry waiting time 1,0 sec 50
b004
Undervoltage trip during stop 00 51
b005
Undervoltage Number of retry 00 51
b006
Input phase loss protection 00 51
b007
Matching frequency setting 0,00 Hz 51
b012
Electronic overload setting FI-I
NOM 36
b212
2nd Electronic overload setting FU-INOM 55
b013
Electronic overload characteristic 01 36
b213
2nd Selection of electronic overload charact. 01 55
b015
Free electronic thermal: frequency 1 0 Hz 36
b016
Free electronic thermal: current 1 0,0 A 36
b017
Free electronic thermal: frequency 2 0 Hz 36
b018
Free electronic thermal: current 2 0,0 A 36
b019
Free electronic thermal: frequency 3 0 Hz 36
b020
Free electronic thermal: current 3 0,0 A 36
b021
Selection of 1st overload restriction 01 37
b022
Level of 1st overload restriction 1,20 x IN 37
b023
Rate of 1st decel. at overload restriction 1,00 s 37
b024
Selection of 2nd overload restriction 01 37
b025
Level of 2nd overload restriction 1,20 x IN 37
b026
Rate of 2nd decel. at overload restriction 1,00 s 37
