Vatech pDRIVE CX profi - Page 109

Operating & Mounting instructions – 8 074 143.03/03 – Appendix A6
C-Parameters
No. Parameter name Factory default Setting Page
C001
Function of input 1 18 38
C002
Function of input 2 16 38
C003
Function of input 3 03 38
C004
Function of input 4 02 38
C005
Function of input 5 01 38
C011
Condition of input C01 00 45
C012
Condition of input C02 00 45
C013
Condition of input C03 00 45
C014
Condition of input C04 00 45
C015
Condition of input C05 00 45
C019
Condition of input FW 00 45
C021
Function of relay 11 01 46
C022
Function of relay 12 00 46
C026
Function of relay AL 05 46
C027
Function of FM PWM output 00 56
C028
Function of AM analog output 00 56
C029
Function of AMI analog output 00 56
C031
Relay output 11: Inversion 00 48
C032
Relay output 12: Inversion 00 48
C036
Relay output AL: Inversion 01 48
C040
Overload signal output mode 00 49
C041
Level of overload signal 1 I
NOM 49
C042
Arrival signal for Acceleration 1 0,0 Hz 49
C043
Arrival signal for Deceleration 1 0,0 Hz 49
C044
PID controller: Level of deviation 3,0 % 33
C061
Level of thermal motor protection 80 % 50
C070
Data command 02 58
C071
Transmission speed 04 58
C072
Identification code 1 58
C073
Data bits 7 58
C074
Parity 00 58
C075
Number of Stop bits 1 58
C078
Waiting time 0 58
C081
Adjustment 0...10 V input Default 22
C082
Adjustment 4...20 mA input Default 22
C083
Adjustment -10...+10 V input Default 22
