2. Choosing an Installation Site
vatech A9 (Model: PHT-30CSS) Installation Manual 11
English
2. Choosing an Installation Site
2.1 Room Requirements
 The equipment’s location must allow the operator to
observe the patient clearly during the imaging.
 The operator must stay close to the patient during the
imaging.
 DO NOT install the equipment on a thick carpet.
 Install the equipment on the anti-static floor.
 Install the PC monitor, Emergency Stop Switch, and X-
ray Exposure Switch close to the operator so that
he/she can use them simultaneously in an emergency.
<Without CEPH Unit (optional): 2,500 mm (L) x 1,700 mm (W) or wider >
1,700 / 67”
2,500 / 98.5”
