4
.
Installi
ng the Equipment: Base Stand (O
ptional)
56
vatech A9
(Model:PHT
-
30CSS
)
Installation Manual
4.4
Fixing the Base (Opt
ional)
Concrete Floor
Required T
ool
Hammer Drill
L
= 200 m
m
(7+
-
.9”)
Ratchet
Wrench
T
ips:
3 mm
- 8
mm
(
0.12”
-
0.3”
)
Hammer
N/A
Parts and
Accessory
Anchor Bolt
5/16 x 60 w/ Sprin
g
and Flat
Washers
-
2 pcs
(Part No. 34)
Spring washer
M8 -
2 pcs
(Part No. 34)
1.
Place the Base Uni
t on the floor where you planned to in
stall the equipment.
And mark two locations to insert anchor bolts. (
see bel
ow)
65
67
