7. Setting up PC
vatech A9 (Model: PHT-30CSS) Installation Manual 87
7.2 The Recommended PC Requirements
It is mandatory to ensure that the PC system
configuration is compatible with the imaging and image
viewer software's PC system requirements.
Since image quality may deteriorate from lack of
resources, observe the requirement guideline specified
in the following tables.
The PC components shall be approved by UL/CSA.
The PC shall be grounded well protectively.
The multiple portable socket-outlets shall not be placed
on the floor.
In case the equipment is to be installed in an area with
an unstable electric power supply, it is strongly
recommended to use the AVR (automatic voltage
regulator) to keep the line voltage stable.
The PC system provided with the vatech A9 undergoes
a rigorous test for software compatibility before shipping.
Therefore, any later changes to the hardware and
software may cause malfunction.
Item Specifications
CPU Intel® Core i3-9100 3.6 4C
RAM 16GB (2x8 GB) DDR4-2666 UDIMM NECC Memory APJ
HDD 1TB SATA 7200 rpm 3.5in WKS
Graphics board GEFORCE GTX1050 Ti DUAL D5 4G
Ethernet Interface Intel Ethernet I210-T1 PCIe x1 Gb NIC
Serial Port (RS232) HP Serial Port Adapter Kit
Power Supply
500 W internal power module, up to 90% efficiency, active
PFC
Slots
M.2 PCIe x1 2230 (for WLAN)
M.2 PCIe x4 2280/2230 Combo (for storage)
PCI Express v3.0 x1
PCI Express v3.0 x16 (wired as x4)
PCI Express v3.0 x16
CD/DVD drive DVD-ROM, DVD+/-RW, Blu-Ray
Monitor 19” 1280x1024 screen resolution
Operating System Windows 10 Professional 64-Bit OS
Recommended
System
HP Z1G5
*. If an ethernet card is not installed in your PC, purchase an Ethernet card separately.
