4
.
Installi
ng the Equipment: Base Stand (O
ptional)
62
vatech A9
(Model:PHT
-
30CSS
)
Installation Manual
4.6
Removing the T
ransportation Safet
y Bolt
s
1.
Lift the V
ert
ical Frame Unit
C
over
, as shown i
n the figure
.
2.
Remove two
S
afety
B
olt
s (
see i
mpor
tant
) along with their tags
.
Required T
ool
Allen Wrench
6 mm / 0.
24”
Avoid damag
ing
the cables w
hen you
are removing
the safety
bolt
s.
the Safety Bolt
s
are locat
ed inside the V
ertical
Frame Unite, as indicated in t
he image below
.
2
1
71
73
