2. Choosing an Installation Site
14 vatech A9 (Model:PHT-30CSS) Installation Manual
Minimum Space Required
Without CEPH unit
2,500 mm (L) x 1,700 mm (W) x 2,700 mm (H)
With CEPH unit
2,500 mm (L) x 2,500 mm (W) x 2,700 mm (H)
Lead Thickness
≥ 1 mm
The width of the Entrance
The X-ray room door should have a clearance of more than 800 mm (31.5”) wide.
Floor Area
The floor of the X-ray room must be stable and level for system balance.
The floor must be able to support a minimum weight of 500 kg/m
2
(110 lbs. / feet
2
)
Protection against Radiation
To protect against radiation hazards, follow all federal and municipal requirements.
During exposure, the operator should follow applicable radiation shielding
requirements and remain at least 2m (7’) from the source of the radiation.
Maintain visible contact with the patient and a clear view of indicators such as the PC's
warning lamp and imaging status.
