4. Installing the Equipment: Base Stand (Optional)

66 vatech A9 (Model:PHT-30CSS) Installation Manual

Leveling the Front and Back

1. Place the Spirit Level vertically, as shown in the image.

2. Turn Screws in marked locations left and right until the Sprit Level bubble comes

to the center.

3. When leveling the equipment is completed, ensure to tighten all eight Screws

until they no longer move.

Important Notes6
