5. Installing the Equipment: Wall Mount
74 vatech A9 (Model:PHT-30CSS) Installation Manual
5.6 Leveling the Equipment
Required Tool
T-shaped Hex
Wench
8 mm / 0.3”
Spirit Level N/A
Ensure to place the Spirit Level s only on the following
figures' locations for an accurate reading.
1. Prepare the Spirit Level.
2. Turn the Rotating Unit clockwise so that the X-ray tube head faces the front, as
shown in the figure.
To Next Page
