14,
C HECKS AND REPLACEMENTS.
14.1,
REPLACING THE SPRAY HEAD.
The spray head (1) has to replaced at least once a month operating as follows:
• Use a screwdriver to prise out the spray head (1) and remove it and the relative
gasket from the unit (2).
• Replace the spray head (1) and the gasket (3).
• Refit the gasket on the spray head taking care that the rounded part “A” of the
gasket faces up.
• Place the spray head on the filter holder.
• Mount the filter holder (3) on the unit (2) first on the left-hand tab turning it until
it fits into place and then on the right-hand tab.
• Mount the filter holder on the machine as if you were making coffee and move
it into position to lock the spray head with the gasket into place.
