8.2,
ELECTRICAL CONNECTION.
• Check that all the switches are in OFF position before electrically
connecting the machine.
• A grounding connection is absolutely obligatory and the system
must comply with the regulations in force in the country of
installation.
• Check that the power supply voltage corresponds to that of the
local mains.
• Remove the grilles positioned on the cup heating plate (1).
• Undo the two screws (2) and lift out the cup heating plate (1).
• Unroll the electric cable (3) contained inside and let it run out through the lower
part of the machine.
• Connect the electric cable (3) to a 16A pentapolar plug (not provided) and
connect it to the electric system.
