18 Kienzle MTCO 1324
Description of the chart
The appropriate chart for the device
(Page 150, figure IV)
Outside the EU, the respective national
approval marks and provisions are valid.
Depending on the full-scale value and the
device design, you may use the following
charts within the MTCO 1324:
When using (ordering) charts,
always ensure that the full-scale
value (1) and the approval mark
(2) of the MTCO 1324 correspond to
the details (3) or (4) on the chart
respectively.
Standard chart Chart for electronical evaluation Approval mark
100-24 EC 4K 100-24/2 EC 4B e1-83
100-3300-24 EC 4K 100-3300-24/2 EC 4B e1-85
125-24 EC 4K 125-24/2 EC 4B e1-83
125-3300-24 EC 4K 125-3300-24/2 EC 4B e1-85
140-24 EC 4K 140-24/2 EC 4B e1-83
180-24 EC 4B e1-83
EC =
=
Chart for the EEC tachograph
Chart for the device design with rpm recording (option),
e.g. Type: 1324.50111 ...
Service only
