20 Kienzle MTCO 1324
The rear side of the chart
(Page 151, figure VII)
The EEC tachograph has two basic chart
types:
c) without rpm recording
d) with rpm recording
1) Entry field for the time groups
This entry field is used for manual
entries of the time groups. Manual
entries are required if, for example, the
crew members work away from the
vehicle and therefore are not able to
operate the tachograph or else in case
of a failure of the time group recording
mechanism.
2) Centre field
In the centre field, up to three vehicle
changes may be entered manually.
The following data is required:
3) Approval mark field
This part of the rear side contains
information on the approval numbers of
the chart and the devices for which the
chart is approved.
4) RPM recording (option)
The temporally exact recording (in rpm)
is carried out on the rear side of the
chart for driver 1.
Note
The markers (4a) will be displayed for
ignition on / off.
time of vehicle change
the registration number of the new
vehicle
odometer reading at start of
journey
odometer reading at end of journey
distance travelled
(may be entered)
