11 CSLD Troubleshooting Actual CSLD Test Problems Analyzed
2 9606260806 -0.159 25.1 1 -0.140 8959 67 16 30.4 32.6 77.32 0.000 0
3 9606260928 -0.039 31.3 1 -0.026 9277 80 18 45.0 44.8 87.45 0.000 0
4 9606261351 0.020 102.1 1 0.031 5404 63 41 25.9 24.3 43.32 0.000 0
5 9606261122 -0.010 41.4 1 0.001 3495 80 21 45.0 44.8 27.45 0.000 0
IA5100
CSLD DIAGNOSTICS: RATE TABLE (excerpt)
T1: UNLEADED
TIME ST LRT AVTMP TPTMP BDTMP TMRT DISPNS VOL INTVL DEL ULLG EVAP
9605270507 0 -0.140 65.9 70.0 73.7 0.00 1271 8521 31.5 24.7 322 0.000
9605290214 0 -0.343 66.0 70.1 72.9 -0.10 1945 4983 17.0 38.9 471 0.000
9605290334 0 -0.172 65.9 70.0 72.8 -0.09 1820 4937 44.0 40.3 473 0.000
9605290444 0 -0.135 65.8 70.0 72.6 -0.11 1770 4911 40.5 41.4 474 0.000
9606020430 0 0.050 70.6 72.2 76.0 -0.07 1660 7254 20.0 16.1 378 0.000
9606020510 0 -0.301 70.5 72.2 76.1 -0.12 1591 7247 31.5 16.8 378 0.000
9606020637 0 -0.193 70.4 72.1 75.8 -0.10 1539 7215 18.0 18.3 380 0.000
9606030317 0 -0.408 69.2 71.8 73.1 -0.13 1584 4802 16.5 38.9 479 0.000
9606030346 0 -0.336 69.1 71.8 73.1 -0.14 1517 4799 21.5 39.4 479 0.000
9606030441 0 -0.249 69.0 71.7 73.1 -0.09 1474 4779 27.5 40.3 480 0.000
9606100451 0 -0.114 68.0 71.2 72.5 -0.12 1411 4303 28.5 41.1 500 0.000
9606110421 0 -0.136 67.8 70.6 72.8 -0.05 1956 7132 28.5 22.5 383 0.000
9606110505 0 -0.049 67.8 70.6 72.9 -0.05 1907 7105 23.0 23.2 384 0.000
9606120357 0 0.148 68.8 70.8 72.7 -0.05 1253 6644 17.0 4.7 403 0.000
9606120601 0 0.133 68.7 70.6 72.2 -0.06 1247 6535 18.5 6.7 408 0.000
9606130439 0 -0.293 73.0 73.4 75.2 -0.14 745 8532 44.0 5.8 321 0.000
9606130608 0 0.324 72.9 73.3 74.8 -0.12 763 8464 16.0 7.3 324 0.000
9606170258 0 -0.254 73.1 75.4 80.0 -0.12 1511 4677 21.5 38.7 484 0.000
9606170334 0 -0.424 73.0 75.5 80.2 -0.16 1373 4672 112.0 39.3 484 0.000
9606180420 6 -1.046 78.9 79.2 82.8 -0.26 1222 6206 49.0 10.3 421 0.000
9606240446 0 -0.350 75.2 79.0 84.5 -0.20 1659 3399 41.0 33.0 539 0.000
IA5100
CSLD DIAGNOSTICS: RATE TABLE (excerpt)
T2: UNLEADED PLUS
TIME ST LRT AVTMP TPTMP BDTMP TMRT DISPNS VOL INTVL DEL ULLG EVAP
9606100818 1 -0.134 67.2 69.2 71.5 -0.04 116 10194 21.5 2.3 231 0.000
9606110159 3 -0.081 67.4 70.1 72.3 -0.02 492 9489 69.5 19.9 273 0.000
9606110346 3 -0.081 67.3 70.2 72.3 -0.01 460 9479 90.0 21.7 274 0.000
9606120140 3 -0.075 67.5 70.3 71.8 -0.03 484 8763 70.0 43.6 310 0.000
9606120329 3 -0.083 67.5 70.4 71.9 -0.02 445 8759 75.0 45.4 310 0.000
9606120614 3 -0.044 67.4 70.5 71.8 -0.02 395 8747 57.5 48.1 311 0.000
9606130250 0 -0.103 68.9 70.6 73.6 -0.04 245 9650 146.5 3.8 264 0.000
9606140214 3 -0.111 68.6 71.2 75.3 -0.02 404 8974 145.5 27.1 300 0.000
9606140515 0 -0.117 68.5 71.4 75.8 -0.02 369 8974 66.5 30.1 300 0.000
9606150445 1 -0.051 68.5 71.6 76.7 -0.03 543 8049 27.5 53.6 343 0.000
9606150557 3 -0.108 68.5 71.8 76.7 -0.02 506 8035 120.0 54.8 344 0.000
9606160322 3 -0.251 70.7 73.0 78.6 -0.04 415 9276 113.5 14.8 284 0.000
9606160601 3 -0.233 70.5 73.1 79.0 -0.04 399 9271 52.0 17.4 285 0.000
9606170504 1 -0.142 70.2 73.4 78.9 -0.04 326 8731 29.0 40.4 312 0.000
9606180317 3 -0.131 70.0 73.8 79.6 -0.02 395 8055 76.0 62.6 343 0.000
9606190158 3 -0.146 69.9 73.9 78.7 -0.03 434 7315 138.5 85.3 375 0.000
9606190524 3 -0.136 69.8 74.1 79.4 -0.03 398 7310 52.5 88.7 375 0.000
9606191045 1 -0.062 69.7 74.1 77.5 -0.05 354 7207 28.0 94.1 380 0.000
Inconsistent rates - not temperature compensating
correctly.
