4-3
4 Diagnostics PLLD
AVAILABLE DIAGNOSTIC SCREENS
•
Comm - This screen contains a report of data transmission and reception results for installed communication
modules.
• Device Assignments - This screens contains modules, their connected devices and the device's primary and
secondary assignments.
• Device Dir - This screen lists the console's installed modules and their connected devices.
• Firmware Upgrade - This screen lists TLS software available for remote download.
• HW Configuration - This screen lists console's module locations and hardware/software details.
PLLD
The PLLD diagnostics provide access to the PLLD Manual Test interface and all PLLD diagnostic reports. Each
report has quick access to the PLLD setup screen.
Current or active reports will not be visible for PLLD Lines that are not configured or inactive. Historic reports will
be available for PLLD lines even if they are not configured or if they are inactive, as long as they have data to
display.
AVAILABLE PLLD DIAGNOSTIC REPORTS AND SCREENS
•
0.1 gph (0.38 lph) Auto-Confirm Report (0.1 gph auto-confirm data)
• 0.1 gph (0.38 lph) Tests Report (0.1 gph diagnostics test results)
• 0.2 gph (0.76 lph) Auto-Confirm Report (0.2 gph auto-confirm data)
• 0.2 gph (0.76 lph) Tests Report (0.2 gph diagnostics test results)
• 3.0 gph (11.3 lph) Tests Report (3.0 gph diagnostics test results)
• Mid-Range Tests Report (mid-range Diagnostics Test Results)
• No-Vent Abort Tests Report (No-Vent Test Aborts Information)
• PLLD Status Report (general status and diagnostic information about PLLD)
• PLLD Manual Test (start or stop PLLD tests manually for one or all lines)
• Pressure Offset Monitor (pressure offset history interface for a pressure offset test)
Probe
The Probe diagnostics contain information/diagnostics about probes. Section 8 of this manual is devoted to probe
troubleshooting.
AVAILABLE PROBE DIAGNOSTIC REPORTS AND SCREENS
•
Density Offset - (current density probe readings and fields to enter tank density and temperature information).
• Density Offset History - (density offset history records).
• Overview- (general information about each probe).
