Veeder-Root TLS-450PLUS - Figure 2-4. Console Board Locations (with Power Supply Protective Cover Removed)

2 System Description System Parts Identification
2-4
Figure 2-4. Console Board Locations (With Power Supply Protective Cover Removed)
Legend For Figure 2-4
Item Description Item Description
1 Power Supply board (access cover
removed)
4 Comm Backplane board
2 CPU board 5 AC Input board assembly (access
cover removed)
3 I/O Backplane board
