13Certicatesandapprovals
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
13 Certicatesandapprovals
13.1 Radio licenses
Radar
The device has been tested and approved in accordance with the cur-
renteditionoftheapplicablecountry-specicnormsorstandards.
Regulations for use can be found in the document " Regulations for
radar level measuring instruments with radio licenses" on our home-
page.
Bluetooth
The Bluetooth radio module in the device has been tested and
approved according to the current edition of the applicable country-
specicnormsorstandards.
Theconrmationsaswellasregulationsforusecanbefoundinthe
document " Radio licenses" supplied or on our homepage.
13.2 Approvals for Ex areas
Approved versions for use in hazardous areas are available or in
preparation for the device series.
Youcanndtherelevantdocumentsonourhomepage.
13.3 Approvalsasoverllprotection
Approvedversionsforuseaspartofanoverllprotectionsystemare
available or in preparation for this device series.
The corresponding approvals can be found on our homepage.
13.4 Foodandpharmaceuticalcerticates
Versions for use in the food and pharmaceutical industries are avail-
able or in preparation.
Thecorrespondingcerticatescanbefoundonourhomepage.
13.5 EU conformity
ThedevicefullsthelegalrequirementsoftheapplicableEUdirec-
tives.ByaxingtheCEmarking,weconrmtheconformityofthe
instrument with these directives.
The EU conformity declaration can be found on our homepage.
13.6 Environment management system
Protection of the environment is one of our most important duties.
That is why we have introduced an environment management system
with the goal of continuously improving company environmental pro-
tection.Theenvironmentmanagementsystemiscertiedaccording
toDINENISO14001.Pleasehelpusfullthisobligationbyobserv-
ing the environmental instructions in chapters " Packaging, transport
and Lagestoragerung", " Disposal" of these operating instructions.

Vega VEGAPULS 11 Specifications

General

Frequency	80 GHz
Protection class	IP66/IP67
Accessory Type	Radar sensor
Purpose	Level measurement
Measuring range (short)	8 m
Beam angle	8°
Accuracy	±2 mm
Communication interface	HART
Measuring range	Up to 8 m
Process temperature	-40 to +80 °C
Process pressure	-1 to +3 bar
Output signal	4...20 mA/HART
Material	Plastic
Protection class (dual)	IP66/IP67
Housing material	Plastic
Power supply	12 - 30 V DC
