3 Product description
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
3 Product description
3.1 Conguration
The scope of delivery encompasses:
•
Radar sensor
•
Counter nut G1
1)
•
Information sheet " Documents and software" with:
– Instrument serial number
– QR code with link for direct scanning
•
Information sheet " PINs and Codes" (with Bluetooth versions)
with:
– Bluetooth access code
•
Information sheet " Access protection" (with Bluetooth versions)
with:
– Bluetooth access code
– Emergency Bluetooth unlock code
– Emergency device code
The further scope of delivery encompasses:
•
Documentation
– Ex-specic"Safety instructions" (with Ex versions)
– Ifnecessary,furthercerticates
Note:
Optional instrument features are also described in this operating
instructions manual. The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
•
Hardware version from 1.0.0
•
Software version from 1.2.0
Scope of delivery
Scope of this operating
instructions
1)
G type threaded connections only

Vega VEGAPULS 11 Specifications

General

Frequency	80 GHz
Protection class	IP66/IP67
Accessory Type	Radar sensor
Purpose	Level measurement
Measuring range (short)	8 m
Beam angle	8°
Accuracy	±2 mm
Communication interface	HART
Measuring range	Up to 8 m
Process temperature	-40 to +80 °C
Process pressure	-1 to +3 bar
Output signal	4...20 mA/HART
Material	Plastic
Protection class (dual)	IP66/IP67
Housing material	Plastic
Power supply	12 - 30 V DC
