AC310 Universal AC Drive Service Manual
Front side 6VREF circuit
Front side +10V Voltage circuit
Backside +10V Voltage circuit
Front side 3.3V Voltage circuit
Capacitors:
C83/C88=100NF/0402,
C87=2.2UF/0603
Resistors:
R25/R205=20K/0402，
R164=2K/0402,
R201=12K/0402,
R165=10K/0402
Triode：Q1=2S C2873
