KC 0016 VEMAG
Seite 2 0870149431 / 130422
Monthly:
• Check that the drive motor current drawn is in the usual range
and that the discharged gas is free from oil; if it is not: change
the exhaust filter (➔ Change of the Exhaust Filter)
In case an inlet air filter is installed:
♦ Check the inlet air filter, if necessary replace
In case of operation in a dusty environment:
♦ Clean as described under ➔ Every 6 Months:
Every 6 Months:
• Make sure that the housing is free from dust and dirt, clean if
necessary
• Make sure that the vacuum pump is shut down and locked
against inadvertent start up
• Clean the fan cowlings, fan wheels, the ventilation grilles and
cooling fins
Every Year:
• Replace the exhaust filter (➔ Change of the Exhaust Filter)
In case an inlet air filter is installed:
♦ Replace the inlet air filter
• Check the inlet screen (e, 261), clean if necessary
• Replace the filter of the gas ballast (f, 440)
Every 500 - 2000 Operating Hours:
Observe the operating instructions from the manufacturer of the
machine which the vacuum pump has become a part of!
• Change the oil (➔ Oil Change)
Oil Change
After switching off the vacuum pump at normal operating tempera-
ture wait no more than 20 minutes before the oil is drained (the oil
shall still be warm when being drained).
• Completely drain the used oil (h)
• Remove the cover of the cleaning port (j), check the oil sump
for residues, mechanically remove the residues if necessary
• Fill in approx. 0.4 litres of vacuum pump oil (a)
• Dispose of the used oil in compliance with applicable regula-
tions
Change of the Exhaust Filter
Eye protection goggles must be worn while changing
the exhaust filter!
• Make sure that the vacuum pump is shut down and locked
against inadvertent start up
• Remove the exhaust cover (k) from the oil separator (i)
• Loosen the screw in the centre of the exhaust filter retaining
spring, but do not remove it at this time
• Press the exhaust filter retaining spring out of the indent and
rotate it
• Remove the exhaust filter retaining spring from the oil separa-
tor (i)
• Pull the exhaust filter out of the oil separator (i)
• Install the new exhaust filter in reserve order
• Dispose of the used exhaust filter in compliance with applicable
regulations
Dismantling and Disposal
The inside of the vacuum pump, the oil and the exhaust filter
can be contaminated with process residues: wear personal
protective equipment as appropriate!
• Drain the oil and dispose of it in compliance with applicable
regulations
• Remove the exhaust filter (➔ Change of the Exhaust Filter)
and dispose of it in compliance with applicable regulations
• Make sure that the vacuum pump is not contaminated with
harmful foreign material
According to the best knowledge at the time of printing of this manu-
al the materials used for the manufacture of the vacuum pump
involve no risk.
• Dispose the vacuum pump as scrap metal
Technical Data
Nominal suction capacity
(50Hz / 60Hz)
m³/h 16 / 19
Ultimate pressure
hPa (=mbar)
abs.
20
Motor nominal rating
(50Hz/60Hz)
kW 0.55
Motor nominal speed
(50Hz / 60Hz)
min
-1
3000 / 3600
Sound pressure level
(DIN EN ISO 2151)
(50Hz / 60Hz)
dB (A) 60 / 64
Operating temperature
(50Hz / 60Hz
°C 65 / 75
Ambient temperature range °C 0 … 40
Ambient pressure Atmospheric pressure
Oil quantity l 0.4
Oil furnished ex-works VSL 068
Weight approx.
(50Hz / 60Hz)
kg ~18
Spare Parts / Spare Parts Kits
The exclusive use of genuine spare parts and consumables is
prerequisite for the proper function of the vacuum pump and
for the granting of warranty, guarantee or goodwill.
Find the list of Busch companies all over the world (by the time of
the publication of these operating and maintenance instructions) on
(➔ rear cover page).
Find the up-to-date list of the Busch companies and agencies all
over the world on the internet at www.busch-vacuum.com.
Pos. Part Qty Part no.
- Vacuum pump, complete
090116702
0 1113 149 029
1 Cylinder 1 0223 140 616
15 Rotor 1 0210 105 135
16 Clamping screw 1 0416 140 926
17 Clamping ring 1 0432 140 927
