Troubleshooting
Problem Possible Cause Remedy
The vacuum pump does not reach the usual
pressure
The drive motor draws a too high current
(compare with initial value after commission-
ing)
Evacuation of the system takes too long
The vacuum system or suction line is not leak-
tight
Check the hose or pipe connections for possi-
ble leak
In case a vacuum relief valve/regulating sys-
tem is installed:
The vacuum relief valve/regulating system is
misadjusted or defective
Adjust, repair or replace, respectively
Contaminated oil (the most common cause)
Change the oil (➔ Maintenance)
No or not enough oil in the reservoir
Top up oil (➔ Maintenance)
The exhaust filter is partially clogged
Replace the exhaust filter (➔ Maintenance)
The screen (e, 261) in the suction connection
(d) is partially clogged
Clean the screen (e, 261)
If cleaning is required too frequently install a
filter upstream
In case a filter is installed on the suction con-
nection (d):
The filter on the suction connection (d) is
partially clogged
Clean or replace the inlet air filter, respectively
Partial clogging in the suction, discharge or
pressure line
Remove the clogging
Long suction, discharge or pressure line with
too small diameter
Use larger diameter
The valve disk of the inlet non-return valve is
stuck in closed or partially open position
Disassemble the inlet, clean the
screen (e, 261) and the valve as required and
reassemble
A shaft seal is leaking Replace the shaft seal ring (Busch service)
The exhaust valve is not properly seated or
stuck in partially open position
Disassemble and reassemble the exhaust
valve (Busch service)
A vane is blocked in the rotor or otherwise
damaged
Free the vanes or replace with new ones
(Busch service)
The radial clearance between the rotor and
the cylinder is no longer adequate
Readjust the vacuum pump (Busch service)
Internal parts are worn or damaged Repair the vacuum pump (Busch service)
WARNING
Risk of electrical shock, risk of damage to equipment.
Electrical installation work must only be executed by qualified personnel that knows and observes the following regulations:
- IEC 364 or CENELEC HD 384 or DIN VDE 0100, respectively,
- IEC-Report 664 or DIN VDE 0110,
- BGV A2 (VBG 4) or corresponding national accident prevention regulation.
CAUTION
During operation the surface of the vacuum pump may reach temperatures of more than 70 °C.
Risk of burns!
Let the vacuum pump cool down prior to a required contact or wear heat protection gloves.
