HP25E / HP30E 4. Setting up
4-1© VEMAG 2018
4. Setting up
4.1 General information
• To set up the machine, select a double screw housing, the double
screws to suit the product to be processed and the required accesso-
ries.
Danger!
To prevent injury, switch o the machine before setting up. Then switch
o the main switch to disconnect the machine from the mains.
4.2 Fitting the double screw housing
Danger!
There is a risk of crushing when tting and removing the double screw
housing and the double screws. To prevent injury, proceed extremely
carefully when tting and dismantling these parts.
• Push double screw housing (1) right into the feed cylinder of the ma-
chine. Inlet bore (2) for product and vacuum should face upwards.
1 Double screw housing
2 Inlet bore
Fig. 4-1
Installing double screw
housing
1
2
