HP25E / HP30E4. Setting up
4-2 © VEMAG 2018
A pin (1) under the coupling pins (2) in the feed cylinder centres the dou-
ble screw housing which has the appropriate bore on its end face.
1 Centring pin
2 Coupling pins
Fig. 4-2
Centring the double screw
housing
1
2
