HP25E / HP30E6. Graphical control
6-24 © VEMAG 2018
6.6.1 Mode groups, modes and views
Use the Operating mode function key to select the mode group,
mode and view. You can set the mode groups and modes in the Service
area.
The mode and view depend on the selected mode group.
For further information about the possible congurations
Section 6.7
6.6.2 Start/stop methods
6.6.2.1 Knee I
The feed element runs only as long as the knee lever is being actuated.
6.6.2.2 Knee II
The feed element runs when the knee lever is actuated briey.
The feed element stops when the knee lever is actuated again.
6.6.2.3 Remote end
The ller is actuated by an attachment via the remote control socket.
The started portion is completed after the attachment stops.
6.6.2.4 Remote stop
The ller is actuated by an attachment via the remote control socket.
The portion is interrupted after the attachment stops.
6.6.2.5 Remote II
The ller is controlled via an external signal (e.g. sensor on conveyor belt
or foot switch). The feed element runs when an external signal was briey
active. The feed element stops if an external signal becomes active again
or the stop counter is on zero.
