VEMAG HP30E - Page 78

HP25E / HP30E6. Graphical control
6-32 © VEMAG 2018
6.6.4.4 Link o󰀨set/clip o󰀨set/knife o󰀨set (minced meat line)
Display: Twist delay / Clip o󰀨set / Knife o󰀨set
Unit: Milliseconds [ms]
Resolution: 1 ms
Setting range: -3,000 – +3,000 ms (default for linking = -25,
default for knife = -60 ms)
Application: Linking / clipping / minced meat line
• Enter o󰀨set.
• Press Enter.
Start linking, clipper/ knife before or after end of portion. Pause time is
adapted automatically here. Advance is limited by speed and portion size.
"0" means linking, clipping or cutting at the end of the portion. A negative
value is limited by portion length.
6.6.4.5 Select double screw (HP series only)
Display: Double screw
Selection: Double screw type (e.g. 48-80)
Application:
Fillers with a double screw (HP series only)
• Enter double screw type.
• Press Enter.
If you select the „grinder“ mode, the selection is restricted to C prole
double screws.
