M-5
04/2005
DISCHARGE
SIDE
VAPOR
HIGH PRESSURE
COMPRESSOR
SUCTION
50°
110°
VAPOR
CONDENSER
FAN
LIQUID
DRIER
LIQUID
CONDENSER
ACCUMULATOR
EVAPORATOR
LOW PRESSURE
CAPILLARY RESTRICTION TUBE
EVAPORATOR
FAN
FIGURE 1
