Vendo VUE 30 User Manual

D-19
05/2006
COIN ENTRY & COIN RETURN ASSEMBLY
ITEM NO DESCRIPTION QTY PART NO
1 COIN INSERT, GFV 1 1125367
LEVER,SCAVENGER ASSY, GFV 1 1125394
2 SHOULDER WASHER,NYLON 1 1122715
3 SCRW 10-16 5/16 B CR HEX TAP 1 V801422
4 (K) SPRING SOLD OUT 1 390326
5 LEVER,COIN RETURN,GFV 1 1127340
6 PIVOT BRKT,COIN RETURN LEVER 1 1127373
7 BUTTON, COIN RETURN 1 1050473
8 DISPLAY, 2X20 SERIAL (LED) 1 1121184
9 COIN CHUTE ASSY, GFV 1 1125397
10 BRKT, COIN INSERT SUPPORT 1 1127058
11 SCREW, #10 -16 X 3/8 B CR HEX STL 2 V801421
12 SCREW, # 8 - 10 X 1/2” LG 5 V802214
13 COIN RETURN CHUTE ASSEMBLY 1 1126488
