Vendo VUE 30 User Manual

C-7
04/2006
POWER DISTRIBUTION ASSEMBLY, 115V
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-10.
ITEM NO DESCRIPTION QTY PART NO
1 POWER DISTRIBUTION ASSEMBLY, 115 V 1 1128115
2 FAN 1 1127890
POWER SUPPLY ASSEMBLY 1 1128111
3 POWER SUPPLY COVER 1 1127365
4 POWER SUPPLY, 24 VOLT DC 1 1127299
5 STANDOFF 4 1121740
6 POWER SUPPLY PLATE 1 1128109
7 ELECTRONIC BALLAST ASSEMBLY 1 1127556
8 RELAY, 24 VOLT DC 3 1125525
9 TRANSFORMER, 24 VAC 1 1111201
10 FUSE HOLDER 1 1128474
11 FUSE, 0.8A/250V, 3AG SLO-BLOW 1 1053864
12 FUSE HOLDER 1 1128473
13 FUSE, 3.15 AMP SLOW BLOW 1 1127484
14 SCREW, 10-16 X 1/2” HEX HEAD 4 V801422
15 SCREW, 10-16 X 5/16” HEX HEAD 16 V801421
16 BUSHING 4 1116634
17 PANEL, POWER DISTRIBUTION 1 1128056
18 HARNESS, POWER DISTRIBUTION (NOT SHOWN) 1 1127482
19 CORD SET 90 DEG. PLUG & IEC (NOT SHOWN) 1 1124281
