* NOTE: WHEN ORDERING FOAMED CABINET ASSEMBLY OR BASE COVER PANEL, PLEASE
PROVIDE 9- CODE AND MANUFACTURER’S DATE CODE.
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-10.
CABINET ASSEMBLY
ITEM NO DESCRIPTION QTY PART NO
1 FOAMED CABINET 1 *
2 CABINET LATCH 3 1125644
3 SCREW, #10 X 3/8” CR TAP 11 V802212
RAMP ASSEMBLY 1 1127193
4 RAMP, DOOR 1 1126224
5 THUMB SCREW, 1/4-20 X .5, RAMP 1 1127060
6 SHIM PLATE, RAMP 1 1127852
7 LEVELING BOLT 4 1059902
8 BASE COVER PANEL 1 *
9 REFRIGERATION ASSEMBLY (SEE PAGE C-4) 1 ~
10 CHANNEL-TRAY SUPPORT 2 1126639
11 HINGE COVER PANEL 1 1128097
12 LIGHT ASSEMBLY (SEE PAGE C-5) 1 ~
13 ANGLE MOUNT, VERTICAL PANEL 3 1127646
14 AIR DUCT ASSEMBLY 1 1127962
15 POWER DISTRIBUTION ASSEMBLY (SEE PAGES C6-C9) 1 ~
16 VERTICAL FOAM PANEL 1 1127988
17 HARNESS, CABINET (NOT SHOWN) 1 1127592
18 PANEL,SCREEN,REAR,41.5” 1 1126686
19 #10 X 1/2” SELF DRILLLING SCREW 6 V801489
