Vendo VUE 30 User Manual

D-14
05/2006
X RAIL ASSEMBLY
ITEM NO DESCRIPTION QTY PART NO
1
RAIL ASSEMBLY - X AXIS - 41.5” 1 1126917
RAIL ASSEMBLY - X AXIS - 34” 1 1127459
2
EXTRUSION RAIL - X AXIS - 41.5” 1 1127460
EXTRUSION RAIL - X AXIS - 34” 1 1127460-1
3 END CAP, X-RAIL, LH 1 1127536
4*
COVER, TOP, X-AXIS DRIVE, 41.5” 1 1127534
COVER, TOP, X-AXIS DRIVE, 34” 1 1127534-1
5 COUPLING, DRIVE 2 1127331
6
SQUARE SHAFT, .25, Y-AXIS, 41.5” 1 1125078
SQUARE SHAFT, .25, Y-AXIS, 34” 1 1125078-1
7 END CAP, X-RAIL, RH 1 1127535
8 PARTITION, RIBBON CABLE 1 1126918
9 REED SWITCH ASY, Y-AXIS 1 1126244
10 BRKT, RTNR, Y-HOME SWITCH 1 1126141
11 TAPPING SCREW - #4 PLASTITE 2 V802186
12 PLATE, TAPPING, END CAP 1 1126142
13 RIBBON CABLE ASSY - X RAIL 1 1127463
14 STANDOFF, PCBA, Y-MOTOR 3 1126194
15 CARRIAGE ASSY, X-AXIS, GFV (SEE D15-D16) 1 1125987
16 SCREW, #8-18 X 1/4 6 V800634
17
STRIP - DRIVE TRACK - X AXIS - 41.5” 2 1127848
STRIP - DRIVE TRACK - X AXIS - 34” 2 1127848-1
18 SPRING, Y-AXIS DRIVE ROD, GFV 2 1126156
19 DRIVE MOTOR, Y-AXIS 1 1129922
20 SHEET, INSULATOR, GFV TRAV BD 1 1126763
21 CLIP, HARNESS, ADHESIVE BACK 1 1030639
22
RTNR, Y-RAIL, X-RAIL ASY, GFV, 41.5” 1 1128319
RTNR, Y-RAIL, X-RAIL ASY, GFV, 34” 1 1128319-1
* NOTE: REFERENCE PART TO BE ORDERED SEPERATELY IS NOT INLCUDED
WITH THIS ASSEMBLY WHEN ORDER
