Veratron VMH 35 - Configuration Options

GENERAL SETTINGS
B001167
UNITS MENU
Setting Description
Possible
values/commands*
Speed
Speed units
K
m
/
h
/ mph/
kts
TRIP
Unit of measurement of distance travelled
km / mile /
nm
Flow
Flow measurement units ...
L/
h
/ gph
Tank
Unit of measurement of the liquid in the tank
L
/ US gal
Temperatures
Temperature units
°C
/ °F
Pressure
Pressure units
bar
/ PSI
Depth
Depth measurement units
m
/ ft
Note*
: the underlined value/command is the default.
SET THE DAY/NIGHT MODE
To set the desired mode, act on pin 10 of the MX150 connector as follows:
To set the mode...
Then...
day
move the pin switch to
GND/OPEN
.
night
move the pin switch to
BATTERY PLUS
.
CHANGE THE BRIGHTNESS OF THE DISPLAY
The change affects the set day or night mode.
