VeriFone V200c User Manual

SYSTEM MODE
System Mode Menus
V200
C REFERENCE GUIDE 27
Home > Administration
Select the Administration panel from the main
System mode menu to change the following PINpad
settings:
To set terminal date and time, select Date/Time.
To set configuration settings for Ethernet, USB
Gadget, Serial, Wi-Fi, iBeacon, USB, or Mini-USB,
select Communications.
To remove user bundle, select Remove user bundle.
To adjust display brightness, select Display.
To set or add extra language, select Language.
To set VHQ configuration, select VHQ Tools.
To adjust volume, select Sound Utilities.
Home > Update
To start download or update the device, select Update
from the main System mode menu, and then select the
Update panel. The following options will be available:
To transfer files via NFS, select NFS.
To transfer file via the USB memory device, select
USB Memory.
To transfer file via the SD memory device, select SD
Card.
To start download via the Serial port, select Serial. The
user has the option to select the port and baud rate.
Selecting AUTO baud allows the serial port to cycle
through the available baud rates until communication
is established.
Netloader is Verifone's proprietary network based
download protocol. To start download/transfer file and
command set over IP from the PC client software,
select Netloader.
Table 4 System Mode Submenus (continued)
Display Action
Date/Time
Administration
Communications
Remove user bundle
Display
NFS
Update
USB Memory
SD Card
Serial
Netloader

VeriFone V200c Specifications

General

Memory	64MB SDRAM
Touchscreen	Capacitive
Connectivity	Ethernet, RS-232, USB
Operating System	Verix
Card Readers	Triple track MSR, EMV smart card reader, Contactless NFC
Power Supply	AC input 100-240V, DC output 5V
Operating Temperature	0°C to 40°C
Certifications	EMV Level 1 and 2, PCI
